BOSS GE-7 Graphic Equalizer Pedal
A great guitar tone isn't always about adding more—it can be about shaping exactly what is already there. The BOSS GE-7 Graphic Equalizer gives guitarists seven independent frequency bands for precise control over their sound, from tightening the low end to adding midrange presence or high-frequency clarity.
Each band offers ±15 dB of boost or cut, providing enough range for subtle refinements or dramatic tonal changes. The GE-7 can be used to compensate for different rooms and amplifiers, create rhythm and lead presets, boost solos, or completely reshape the character of your guitar.
With its intuitive slider layout and dependable BOSS construction, the GE-7 remains one of the most practical tone-shaping tools for a guitar pedalboard.
Key Features
- Seven-band graphic EQ designed for guitar
- Frequency range from 100 Hz to 6.4 kHz
- ±15 dB boost or cut per frequency band
- Individual slider controls for precise tonal shaping
- LEVEL control for overall output
- Excellent for tone correction, solo boosts, and sound customization
- BOSS compact pedal construction
- 9V battery or optional BOSS PSA-series AC adapter
Northeast Music Center
At Northeast Music Center, we know that small changes in frequency can make a major difference in how a guitar sits in a mix. The GE-7 gives players a straightforward way to fine-tune their sound, solve tonal problems, and create additional voices from the same guitar and amplifier.
- Specifications
- Nominal Input Level
- -20 dBu
- Input Impedance
- 1 M ohm
- Nominal Output Level
- -20 dBu
- Output Impedance
- 1 k ohm
- Recommended Load Impedance
- 10 k ohm or greater
- Bypass
- Buffered bypass
- Controls
- Level Control knob
Equalizer Control knob
100, 200, 400, 800, 1.6 k, 3.2 k, 6.4 kHz
Pedal switch - Indicator
- CHECK indicator (Serves also as battery check indicator)
- Connectors
- INPUT jack: 1/4-inch phone type
OUTPUT jack: 1/4-inch phone type
DC IN jack - Power Supply
- Carbon-zinc battery (9 V, 6F22)
Alkaline battery (9 V, 6LR61)
AC adaptor (PSA series: sold separately) - Current Draw
- 30 mA
- Expected battery life under continuous use
- Carbon: Approx. 9 hours
Alkaline: Approx. 19.5 hours
*These figures will vary depending on the actual conditions of use. - Accessories
- Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTES," and "Information")
Carbon-zinc battery (9 V, 6F22) - Options (sold separately)
- AC adaptor: PSA series
- Size and Weight
- Width
- 73 mm
2-7/8 inches - Depth
- 129 mm
5-1/8 inches - Height
- 59 mm
2-3/8 inches - Weight (including battery)
- 400 g
15 oz
